Sinotruk Howo 8x4 Dump Truck

Sinotruk Howo 8x4 Dump Truck

Vehicle type
Dump Trucks
Model
ZZ3257N3647A
Engine
WD615.47
Curb weight(kg)
12290
Drive type
8x4
Dimension(mm)
8214x2496x3386
Product Introduction
Product Introduction
  1. Powerful engine: Equipped with a powerful diesel engine, this truck offers excellent torque and horsepower, ensuring smooth operation even under heavy loads.

  2. Heavy-duty chassis: The truck’s chassis is built to withstand extreme conditions, with reinforced steel components and a durable suspension system.

  3. Large payload capacity: The 8×4 dump truck can carry a significant amount of cargo, making it suitable for transporting large volumes of materials.

  4. Efficient dumping mechanism: The hydraulic dump body allows for quick and easy unloading of materials, reducing labor costs and increasing productivity.

  5. Advanced safety features: The truck is equipped with various safety systems, including ABS brakes, air suspension, and advanced lighting systems, ensuring optimal driver visibility and control.

  6. Comfortable cab: The spacious and well-equipped cabin provides a comfortable working environment for the driver, with features such as air conditioning, heating, and adjustable seats.

  7. Fuel efficiency: Despite its heavy-duty capabilities, the Sinotruk Howo 8×4 dump truck is designed to minimize fuel consumption, helping to reduce operating costs and environmental impact.

SINOTRUK HOWO 8X4 DUMP TRUCK

The Sinotruk Howo 8×4 dump truck is a heavy-duty vehicle designed for efficient transportation and loading of various materials. This truck features an eight-wheel drive configuration, providing superior traction and stability on challenging terrains. The Howo model is known for its robust construction and high performance, making it an ideal choice for demanding applications in industries such as mining, construction, and waste management.

sinotruk howo dump truck -9
Product Parameters
SINOTRUK HOWO 8X4 DUMP TRUCK
Truck Model ZZ3257N3647A  (LHD)
Dimension(Lx W xH)(unloaded) 8214x2496x3386
Cargo body size (L*W*H, mm) 5400x2300x1400
Cargo body thickness(mm)  bottom:8mm, side:6mm,
Lift type of Carriage  Ventral lifting
Approaching angle/Departure angle(°)  19/26
Overhang(front/rear) (mm) 1500/1739
Wheel base (mm) 3625+1350
Max speed(km/h) 75
Curb weight(kg) 12290
Loading Weight(kg) 30000
Fuel tanker capacity  300L with locking fuel cap
Fuel consumption(L/100km) 32
Clutch  Single-plate dry clutch Φ420mm
Engine Model Model  WD615.47,
(Steyr technology, made in China) Power (kw/rpm) 371HP,247/2200
Emission Standard  EURO II
Transmission  Model HW 19710,10 forwards and 2 reverse
Brake system Service brake Dual circuit compressed air brake
Parking brake spring energy, compressed air operating on rear wheels
Auxiliary brake  Engine exhaust brake
Steering system  Model ZF8098 hydraulic steering with power assistance
Front Axle Loading:9000KG
Rear axle
Color  Optional
Tire  12R22.5   11 pieces
Electrical system Operating voltage 24V,negative grounded
Starter 24V,7.35KW
Alternator 28V,1500W
Batteries 2*12V.165Ah
Cigar-lighter, horn, headlamps, fog lights,
brake lights, indicators and reverse light.
Cab HW76 cab, (one sleeper, with air-condition),
Product Applications
sinotruk howo dump truck -9
SINOTRUK HOWO 8X4 DUMP TRUCK
sinotruk howo dump truck -8
SINOTRUK HOWO 8X4 DUMP TRUCK
sinotruk howo dump truck -7
SINOTRUK HOWO 8X4 DUMP TRUCK
sinotruk howo dump truck -3
SINOTRUK HOWO 8X4 DUMP TRUCK
