| SINOTRUK HOWO TX 430HP TRACTOR TRUCK | ||
| Chassis Model | ZZ4257V324GB1R | |
| Drive type | 6×4 | |
| Kerb Weight(kg) | 8960 | |
| GCW(kg) | 50000 | |
| Dimensions LxWxH(mm) | 6800×2500×3225 | |
| Wheelbase(mm) | 3200 | |
| Cabin | Model | TX-F |
| Engine | Model | MC11.43-30 |
| Horse Power(Hp) | 430 | |
| Maximum torque(N ·m/rpm) | 1500N ·m/1050-1400rpm | |
| Rated power(kW/rpm) | 319kW/1900rpm | |
| Emission | Euro Ⅲ | |
| Displacement | 11 L | |
| Transmission | Model | HW25716XAL |
| TYPE | Manual-Automatic | |
| Gear position | 14 forwards &2 reverses | |
| AXLE | Front axle Load capacity(kg) | VGD71 (Drum) 7100 |
| rear axle Load capacity(kg) | MCJ12BGY 12000×2 | |
| Ratio | 3.70 | |
| Chassis | Thinkness(mm) | 8/280 |
| Suspension | Type | Leaf springs(3/5) |
| Steering | Model | Bosch |
| Fifth Wheel | Model | 2.5 inch |
| Fuel tank capacity | Volume(L) | 600 |
| Tire | Mode | 12.00R24,315/80R22.5 |
